Wide-Frame Thermal Break Aluminum Hinged Door
  1. Wide-Frame Thermal Break Aluminum Hinged Door
  2. Wide-Frame Thermal Break Aluminum Hinged Door

Wide-Frame Thermal Break Aluminum Hinged Door

Product Item：AMJ 100T Series Casement Door
✓ Best for custom entrances, villas, apartments, and light commercial projects requiring a wider frame.

✓ Single doors, double doors, sidelights, high thresholds, and low thresholds are available.

✓ 102mm system depth with 2.0mm aluminum profiles and a 20mm thermal break.

✓ Door leaf sizes from 500–1000mm wide × 1800–2600mm high, up to 60kg.

✓ Low-E insulated glass up to 26mm, with HK Kinlong hardware.

✓ Custom sizes, colors, glass, hardware, thresholds, fixed panels, and installation options are available.

NFRC / CSA requirements can be reviewed by project.

Production from approximately 25 days · Standard 7-year warranty
Send Inquiry Live chat
  • Product Detail
  • FAQs

Wide-Frame Thermal Break Aluminum Hinged Door
宽框断热铝合金铰链门

This wide-frame thermal break aluminum hinged door uses a 102mm system depth for custom residential and light commercial entrances.
这种宽框式隔热铝制铰链门，其系统深度为 102 毫米，非常适合用于住宅和小型商业场所的出入口。

It supports single doors, double doors, fixed sidelights, and high or low thresholds with HK Kinlong hardware and Low-E insulated glass.
该产品支持单门、双门设计，可配备固定的侧窗；同时也能适应高低不同的门槛。其配件为 HK Kinlong 品牌的产品，玻璃则采用低辐射隔热玻璃。

2.0mm 2.0 毫米 Aluminum Profile
500–1000mm Single Door Width
1800–2600mm Single Door Height
60kg Maximum Door Leaf Weight
26mm Maximum IGU

Why Choose This Wide-Frame Hinged Door?
为何选择这款宽框铰链门？

Choose this model when you need a wider frame and straightforward entrance layouts without the added screen system.
如果您需要更宽敞的框架结构、简洁明了的入口设计，且不需要额外的屏幕系统，那么请选择这款型号。

You Need a Wider Frame
你需要一个更宽的框架/你需要采用更宽的视角来思考问题。

The 102mm system depth works well for custom entrances that need a broader frame profile.
102 毫米的系统深度非常适合那些需要更宽的框架结构的定制式入口。

You Want a Practical Door Size
你想要一个实用的门尺寸吧。

Each leaf can be 500–1000mm wide and 1800–2600mm high, with a listed maximum weight of 60kg.
每片叶子的宽度在 500 至 1000 毫米之间，高度则在 1800 至 2600 毫米之间。其最大重量为 60 公斤。

You Need Threshold Choices
你需要做出相应的阈值选择。

The system supports both high-threshold and low-threshold entrance details.
该系统既支持高门槛的准入条件，也支持低门槛的准入条件。

You Want Simple Hardware 你想要的是简单的硬件设备而已。

HK Kinlong hardware in black or white is the standard setup for this hinged door.
HK Kinlong 品牌的黑色或白色五金件，是这种铰链门的标配。

Project Options, Thresholds, and Performance

The main project choices are shown here without repeating the size and weight data above.

Project and System Options

InstallationNail fin, mounting tabs, or screws.
Available layoutsSingle door, double door, left or right fixed panels, high threshold, and low threshold.
System dimensions102mm depth; 55mm vertical and top frame; 89.9mm door leaf; 70mm mullion; 20mm frame and leaf thermal break; 14.8mm conversion edge.
ScreenNo screen option is listed for this system.

Threshold Options

High Threshold50mm interior height / 30mm exterior height.
Low Threshold12mm / 20mm, as listed in the current specification.
Door leaves wider than 900mm or taller than 2200mm require four hinges according to the current specification.
≥2.4 W/m²·KEstimated U-Value
300PaEstimated Water Resistance
3.6 m³/(m·h)Estimated Air Leakage
≤4000PaEstimated Wind Pressure
33dBEstimated Sound Insulation

Performance figures are estimated references from the latest AMJ product specification. Final results depend on door size, glass, configuration, installation, and the applicable project test report.

Available Aluminum Hinged Door Layouts

Final swing direction, fixed panels, threshold type, and structural details should be confirmed from the project drawings.

Single Hinged Door

One operable aluminum door leaf.

Double Hinged Door

Two operable leaves for a wider entrance.

Door with One Sidelight

One door beside fixed glass.

Door with Two Sidelights

A centered door with fixed glass on both sides.

High or Low Threshold

Choose the sill detail that fits the floor condition.

Our Strength

Checking and Alignment

1. Checking & Alignment

Cutting and Punching

2. Cutting & Punching

Milling Holes

3. Milling Holes

Assembly

4. Assembly

Glass Assembly

5. Glass Assembly

Packaging

6. Packaging

Delivery

7. Delivery

Installation

8. Installation

Drawing and Engineering Review

Drawing & Engineering Review

Sample Support

Sample Support

Quality Inspection

Quality Inspection

U.S. Showrooms

U.S. Showrooms

Local On-Site Support

48-Hour On-Site Support

Warranty Service

Warranty Service

NFRC Certificate

NFRC

CSA Certificate

CSA

ENERGY STAR Certificate

ENERGY STAR

ISO Certificate

ISO

Which Aluminum Hinged Door Fits Your Project?

Only the main customer-visible differences are shown below.

Standard Thermal Break Aluminum Hinged Door

Standard 67mm system with 24mm thermal break and up to 36mm IGU.

High-Insulation Aluminum Hinged Door

78.3mm system with 35.3mm thermal break and up to 47mm IGU.

CURRENT

Wide-Frame Thermal Break Aluminum Hinged Door

102mm wide-frame system with high or low threshold options.

Screen-Ready Thermal Break Aluminum Hinged Door

102mm system with stainless steel or aluminum mesh screen configurations.

Frequently Asked Questions

When are four hinges required?

Four hinges are required when the door leaf is wider than 900mm or taller than 2200mm.

What information should I send for a quotation?

Send the project location, rough opening sizes, door layout, quantity, glass, finish, threshold or screen requirements, installation detail, and delivery ZIP code to info@amjbm.com.

What is the minimum order quantity?

We offer flexible MOQs. Sample sets can be reviewed before bulk production, and tiered pricing is available for full container load project orders.

How long do production and shipping take?

Standard production can be as fast as 25 days after drawings, sizes, glass, finish, and hardware are confirmed. Larger or more complex orders may take about 30–55 days. Transit time depends on the destination and carrier schedule and is confirmed before shipment.

What warranty is included?

A standard 7-year warranty is available for the ordered door system, subject to the final order terms and normal use. Longer warranty options may be reviewed for qualifying projects.

Start Your Wide-Frame Hinged Door Project

Send your drawings, door schedule, rough opening sizes, or BOQ for glass, threshold, hardware, layout, and project pricing.

Request a Project Quote Chat on WhatsApp


Here are the key questions project buyers, contractors, developers and distributors usually ask before working with AMJ.

Are you a factory?
Yes. AMJ is a factory-based aluminum window and door manufacturer in Guangdong, China, with our own production plant, technical team, equipment, QC process, and export packaging system.
What should I send for a quotation?
Please send project drawings, window and door schedule, sizes, quantities, glass requirements, frame color, hardware options, project location, and expected delivery time.
Can you customize products according to project drawings?
Yes. We can customize sizes, opening styles, glass, colors, hardware, and system solutions according to your drawings and project requirements.
Are your products suitable for export projects?
Yes. We provide aluminum window and door solutions for residential, commercial, and custom projects, and can match suitable configurations according to different market requirements.
Do you have certifications or test reports?
Yes. AMJ has NFRC, CSA and ISO management system certifications, and experience with AS2047 / AGWA requirements for the Australian market. Project-specific testing can also be arranged if needed.
What types of aluminum windows and doors do you offer?
We offer casement, sliding, awning, double hung, tilt-turn windows, as well as sliding, casement, bi-fold, pivot and other aluminum door systems.
How do you control quality before shipment?
Before shipment, we check profiles, glass, hardware, dimensions, surface finish, opening operation, sealing, assembly quality, and packaging. Photo/video inspection or third-party inspection is also available.
How do you package products for export?
We use reinforced export packaging, protective film, corner protection, foam, crates or steel frames, and clear job-site labels to reduce damage and support easier installation.
What is your normal production lead time?
Normally, production takes around 25–35 days after drawings, specifications, payment terms, and production details are confirmed. The exact lead time depends on order quantity, product system, glass, color, and hardware configuration.
What warranty and after-sales support do you provide?
AMJ provides up to 10 years product warranty depending on the product system, glass, hardware, and project conditions. We also provide installation guides, installation videos, technical support, spare parts support, and project follow-up service.
...
